Tractor/Tiller/Trailer Rental

Kubota B2601 4×4 Compact Tractor Loader

4′ 3-point tiller

Dual axle trailer

$285/Day

Call 989.266.3600 to make a reservation.

Category:

Description

Kubota B2601 4×4 Compact Tractor Loader

4′ 3-point tiller

Dual axle trailer

$285/Day

Call 989.266.3600 to make a reservation.

  • Type E-TVCS, liquid cooled, 3 -cylinder diesel
  • Make Kubota D1105
  • PTO power HP (kW) 19.5 (14.5)
  • Engine gross power HP (kW) 24.3 (18.1)
  • Rated RPM rpm 2800
  • Bore and stroke in (mm) 3.1 × 3.1 (78 × 78.4)
  • Displacement cu. in. (cc) 68.5 (1123)
  • Air cleaner Dual paper element
  • Lubrication Forced lubrication
  • Cooling system Pressurized radiator
  • Radiator fan Radial air flow
  • Fluid Capacities
  • Fuel tank gal (l) 6.1 (23)
  • Cooling system qts (l) 4.0 (3.8)
  • Engine oil qts (l) 3.3 (3.1)
  • Transmission case gal (l) 4.0 (15)
  • Drive Train/Transmission
  • Transmission type HST (3 ranges)
  • Differential lock – Rear axle Standard
  • Final drive Spur gear
  • Brakes Multi-plate wet disc
  • PTO
  • PTO Type Independent
  • Rear PTO rpm 540
  • Mid-PTO rpm 2500
  • Hydraulic System
  • Type Open center
  • Pump Dual pump
  • Total pump output gpm (l /min.) 8.3 (31.4)
  • Hydraulic outlet Rear outlet
  • 3-Point hitch Category I
  • Hydraulic control system Position control valve
  • Lift capacity
  • At lift points lbs (kg) 1808 (820)
  • 24″ behind lift point lbs (kg) 1411 (640)
  • Steering type Hydraulic power steering
  • Tires
  • Front (Farm) 7-12
  • Rear (Farm) 11.2-16
  • Travel Speed
  • Forward mph (km/h) 0-12.7 (0-20.4)
  • Reverse mph (km/h) 0-9.5 (0-15.3)
  • Dimensions
  • Overall length (w/o 3P) in (mm) 94.9 (2410)
  • Overall width (min tread) in (mm) 49 (1245)
  • Overall height in (mm) 85.0 (2160)
  • Wheelbase in (mm) 61.4 (1560)
  • Ground clearance in (mm) 12.8 (325)
  • Turning Radius feet (m) 6.9 (2.1)
  • Weight lbs (kg) 1632 (740)
